SB5-16 CNC Automatic Stirrup Bender
Category:CNC Stirrup Bender
Parameter:1. Single Wire Diameter: ¢5-16mm
2. Double Wires Diameter: ¢5-12mm
3. Max. Straightening Length: 6m (or customized)
4. Long Bar Straight Assist Devise: 6m (or customized)
5. Max. Length of Stirrup Side: 2350mm
6. Min. Length of Stirrup Side: 100mm
7. Max. Pulling Speed: 110m/min
8. Max Bending Speed: 1200°/sec
9. Max. Bending Angle: 180°
10. Length Tolerance: ±1mm
11. Angle Tolerance: ±1°
12. Production Capacity: 2000pcs/h
13. Total Power: 69KW
14. Rated Voltage: 380V
15. Machine Size: 3.05*1.62*2.15m (Main Machine)
16. Weight: 11000KG
17. Bending Direction: Bi-direction
18. Operation: Automatic Wire Feeding System (CNC)
