SB4-10A CNC Automatic Stirrup Bender

Parameter：1. Single Wire Diameter: ¢4-10mm 2. Double Wires Diameter: ¢4-8mm 3. Max. Length of Stirrup Side: 1200mm 4. Min. Length of Stirrup Side: 130mm 5. Max. Pulling Speed: 90m/min 6. Max Bending Speed: 900°/sec 7. Max. Bending Angle: 180° 8. Length Tolerance: ±1mm 9. Angle Tolerance: ±1° 10. Production Capacity: 1600pcs/h 11. Total Power: 20.2KW 12. Rated Voltage: 380V 13. Machine Size: 3.7*1.2*1.9m 14. Weight: 1750KG 15. Bending Direction: Unidirection 16. Operation: Automatic Wire Feeding System(CNC)
